Honda's GX series engines have low noise levels, low vibration and low emissions, all without sacrificing power output or performance. This engine is legendary for superior reliability and performance. Common applications include compaction equipment, pumps, pressure washers and more.
Precision camshaft design offers precise valve timing and optimal valve overlap, OHC design for increased efficiency and optimal power transfer, and High compression ratio for better fuel efficiency
Precision engineered components result in lower vibration
Ball bearing supported crankshaft for greater stability
Muffler and breather valve enhancements reduce noise and improve sound quality
New carburetor chamber coating and carburetor filter help to protect against fuel impurities
Simple throttle control, large fuel tanks, large automotive type fuel cap, dual oil drains and fill, easily accessible spark plug
| ENGINE SPECIFICATIONS |
| ENGINE BRAND |
Honda |
| MODEL NUMBER |
GX200 QX2 |
| WARRANTY |
3 Year Residential | 3 Year Commercial |
| POWER OUTPUT |
5.8 HP @ 3600 RPM |
| TORQUE |
9.1 lb-ft (12.4 Nm) @ 2500 rpm |
| CRANKSHAFT ORIENTATION |
Horizontal |
| CRANKSHAFT TYPE |
Straight |
| CRANKSHAFT DIAMETER |
3/4" |
| CRANKSHAFT LENGTH |
2-7/16" |
| END TAPPED SIZE |
5/16"-24 |
| KEYWAY |
3/16" |
| ROTATION DIRECTION |
Counter-Clockwise |
| STARTER TYPE |
Recoil |
| IGNITION SYSTEM |
Transistorized Magneto |
| CARBURETOR |
Butterfly |
| NUMBER OF CYLINDERS |
One |
| CYLINDER BORE |
Cast Iron Sleeve |
| AIR CLEANER |
Dual Element |
| OIL CAPACITY |
0.63 qt |
| FUEL |
Unleaded 86 Octane or Higher |
| FUEL PUMP |
N/A |
| GOVERNOR SYSTEM |
Mechanical |
| CONTROLS |
Manual Choke, Manual/Remote (Rod) Throttle |
| BORE x STROKE |
68mm x 54mm |
| COMPRESSION RATIO |
8.5 : 1 |
| CHARGING SYSTEM |
N/A |
| MUFFLER |
Standard |
| FLYWHEEL |
|
| ENGINE NOTES |
|
| REPLACES |
GX200QX2, GX200 QX2, GX200T1QX2, GX200UT1-QX2, GX200UT2-QX2, GX200UT2QX2, GX200K1QX2, GX200K1-QX2, GX200QX2, GX200-UT1-QX2, GX200-T1-QX2, GX200-UT1-QX2, GX200QX2 |
|
COMMON APPLICATIONS
*This engine is commonly used for, but not limited to, these applications*
|
Air Compressors, Chipper Shredders, Plate Compactors, Compost Grinders, Concrete Saws, Hydraulic Pumps, Log Splitters, Plate Compactors, Tillers, Water Pumps |
|
COMMON EQUIPMENT MANUFACTURERS
*This engine is commonly used on, but not limited to, these equipment manufacturers/brands*
|
Ariens, DR, Husqvarna, Montgomery Ward, Merry Tiller/MacKissic, Murray, Sanborn, Tomahawk, Troy Bilt, Wacker Neuson
|
